Abnormal. Unprecedented. Remarkable. Extreme. These words are supposed to describe unusual events, but in the weird world we’re now entering, the extreme has become commonplace. Some people call this emerging state of affairs ‘the new normal.’ A more direct descriptor is ‘spiraling into climate chaos.’
Chaos is an apt word to describe the scene in the Arctic this week as one of the most powerful summer cyclones ever to form rages in a place that has just experienced a record-shattering influx of atmospheric heat. This storm is hammering the sea ice, pushing it nearly to the second-lowest extent on record. But worse may be still to come as a very weak and diffuse ice pack is predicted to face off against a storm that’s expected to significantly reintensify on both Friday and Tuesday.
Record Arctic Heat
The Arctic. It’s a place we typically associate with frozen things. Due to the billions and billions of tons of heat-trapping gasses dumped into the atmosphere each year by burning fossil fuels, now it’s a place that’s thawing at a disturbingly fast pace. The region could best be described in these few words — record abnormal warmth in 2016.
(This graphic from University of California, Irvine Ph.D. candidate Zack Labe is a visual measure of a stunning jump in Arctic temperatures for 2016. So much heat in the Arctic has profound implications, not just for the Arctic ice and environment, but for the rest of the world as well. In other words — warming that happens in the Arctic doesn’t stay in the Arctic.)
So far, 2016 has seen temperatures in the Arctic that are well above the warmest previous year ever recorded. This big spike in a decades-long trend includes, for this single year, about 35 percent of all the temperature rise experienced there since the late 1940s. It’s like taking more than a third of all the warming in the Arctic seen over the past 68 years and cramming it into just one year. It’s insane.
The Warm Storm Generator
Heat in the Arctic doesn’t just emerge there. It comes, largely, in the form of energy transfer.
Heat-trapping gasses warm the atmosphere in an uneven fashion. The way these gasses absorb solar radiation results in more heat trapping during the dark of night. And the Arctic experiences a thing called polar night which lasts for months.
As a result, the Arctic already gets a slightly more powerful nudge from global warming than the rest of the world. As the cold begins to fail in the Arctic, a number of amplifying feedbacks come into play that further multiply the warmth.
(A dance of cyclones. GFS model rendering by Earth Nullschool shows a strong influx of heat from the Eurasian Continent and the Barents and Kara Seas feeding into a bombing low-pressure system on Monday at 12:00 UTC. The low is predicted to meet up with the currently raging Arctic cyclone by late Monday or early Tuesday. Combined, these lows are expected to drop into the 960s to 970s mb level, extending the scope of the strong event and possibly resulting in the most powerful cyclone ever to have formed this time of year in the Arctic Basin. Image source: Earth Nullschool.)
As the Arctic heats up, its natural barriers to heat coming up from the ocean or from the south begin to fail. The more evenly-warmed surface of the ocean transfers some of its heat north and pumps this added energy into the Arctic air. The lower sea-ice levels cause this water to warm even more, its dark surface trapping more of the summer sun’s warmth than the white ice ever could.
The polar Jet Stream begins to weaken as the relative difference between Arctic and lower-latitude temperatures drops. In the Jet Stream’s meanders, strong warm winds blow in from the ever-hotter continents and ocean surfaces of the mid and upper latitudes.
It’s a simple physical property of the atmosphere that burgeoning heat often seeks out the cold. It rises as it flows toward the Pole, and when it collides with these chilly pockets, the result can be an atmospheric maelstrom.
The Great Arctic Cyclone of 2016 Smashes Sea Ice
Such was the case earlier this week as a warm tongue of air flowed up into area of the Laptev Sea from Siberia. This warm flow tapped moisture from the Kara and Barents Seas and fed into a developing storm system (see article here). Pressures at the storm’s center rapidly fell and by late Monday, August 15th, had dropped to 966.5 millibars. The result was one of the strongest cyclones ever to form over the Arctic Ocean during August.
(We’ve probably never seen the ice so thin near the Pole during August. Zack Labe‘s rendering of SSMIS sea ice concentration measures from late July to August 17 shows a stunning degree of thinning and loss. Note the large, low-concentration holes opening up near the Pole in the final few frames.)
The storm rampaged through the Arctic. Pulling in strong winds and heavy surf, it smashed the sea ice, driving daily extent losses to 110,000 square kilometers on Tuesday and greatly thinning a vulnerable tongue of ice running out toward the Chukchi Sea. Meanwhile, near the Pole, great gaps 50 to 100 miles wide have opened up, revealing water that is 80 percent clear of ice.
The storm subsequently weakened, with pressures rising today into the 985 mb range. But over the next few days, the system is predicted to reintensify — first on Friday to around 971 to 978 mb as it approaches the Canadian Arctic Archipelago, and then again on Tuesday to around 963 to 976 mb when it loops back toward the Laptev.
(AMSR2 and SSMIS sensor reanalysis shows that 2016 Arctic sea ice area [black line] in the Central Arctic Basin — a key region for indicating sea ice health — hit new record lows over recent days. A signal pointing to risk that a challenge to 2012 records may emerge in some measures over the coming days as the 2016 cyclone is expected to re-intensify. Image source: The Great White Con.)
In each case, the storm is predicted to draw on heat, moisture, and low-pressure cells riding up from the south, with the first stream of energy feeding into this low from over the Beaufort and Bering Seas and northeastern Siberia, and the second running up from the Barents and Kara Seas, western Siberia and northeastern Europe (you can see the succession of lows and moisture here in this model run by Climate Reanalyzer).
If this happens, we’ll be coming out of a situation where a warmth-fueled Arctic cyclone will have bombed to record or near-record strength on two to three separate occasions, all the while applying its buzz-saw winds, waves and Coriolis forces to the sea ice — a full-blown nightmare Arctic sea-ice melt scenario in the midst of a record-hot year.
A recent report by expert ice observer Neven over at the Arctic Sea Ice Blog (which is very informative) finds that storm impacts thus far have been significant, if not yet quite as extraordinary as the Great Arctic Cyclone of 2012. Overall sea ice area measures (not just those in the Central Arctic Basin indicated above) according to Wipneus have dropped into second lowest on record just below the 2007 line. Extent, meanwhile, in the JAXA measure after falling an average of 90,000 square kilometers per day, is today at third lowest on record — trailing 2007 by just 30,000 kilometers. Tracking for end of year now appears most likely to fall into a range near 2007 in many measures. But the current storm appears to have provided a potential for a stronger downward trend for the ice in which some measures (particularly various regional measures) have the potential to approach or exceed 2012.
(Peering through the clouds on August 19 in this LANCE MODIS satellite shot we find that sea ice in the Chukchi appears to have been greatly reduced and thinned by the current cyclone. Loss and thinning of the ice bridge with the main pack means that this ice may have also suffered separation. Toward the Laptev, sea ice in the pack between that Arctic sea and the Pole is extraordinarily mobile and becoming more diffuse. These observed conditions still present a potential for large daily losses and further reductions in total sea ice coverage. So current tracking comes with a ‘risk of downside’ caveat. Image source: LANCE MODIS.)
One final point is that we are entering La Nina and such events tend to increase heat transport toward the Arctic and particularly into the Arctic Ocean. For this reason El Nino year +1 or El Nino year +2 can tend to present higher risk for greater sea ice melt totals. As such, and dramatic as the heat and melt in the Arctic has been for this year, it’s worth noting that what we may be watching is a set-up for 2017 or 2018 to see worsening conditions. La Nina is currently expected to be weak, so the related North Atlantic influence (NAO) that has been so devastating to the ice during the recent record warm years may be somewhat muted. We’ll have to see.
2016, however, is not entirely out of the woods. Thin ice in the Chukchi and an increasingly thin and diffuse pack extending from the Pole toward the Laptev remain very vulnerable to late season flash melt and compaction. Model runs today indicate the current set of storms tending to restrengthen on one or two occasions back to the 970s or 960s before finally ebbing on Wednesday. After this, some models show a tendency to flip toward a strong high pressure influence which would again wrench the ice (this time toward compaction). So the troubling 2016 Arctic melt drama is still far from over.
